Cutera Asclepion Juliet Rejuvenation –

Cutera Juliet CONSUMABLES & RECERTIFICATION

Does Cutera Charge a One Time Recertification Fee for the Purchase of Consumables? Yes

Cost of Recertification: $30,000

Consumables Required: Disposable Vaginal Probe & Pink Smartcard

Cost for Consumables: Box of 12 Probes & Includes 150 Unit Pink Smartcard = $900

Cutera Juliet PRODUCT SPECIFICATIONS

Laser Type: Erbium Yag

Wavelength: 2940 nm

MANUFACTURER NOTES – for Skin Rejuvenation

Juliet is a versatile multi-application platform utilizing an Er:YAG laser with the 2940 nm wavelength. This Erbium wavelength produces noticeable results with fewer side effects, due to its high peak absorption in water. Additionally, Juliet’s Erbium technology allows for a controlled thermal delivery to tissue, keeping the procedure safe for patients while being effective.

The Juliet laser incorporates a unique treatment protocol by delivering two passes of energy to tissue with minimal downtime and high patient satisfaction.

Juliet Technology

Juliet selectively targets the treatment area by delivering the right combination of ablation and coagulation for optimal outcomes with limited side effects.

Unique Two-Pass Approach

Juliet delivers two passes of energy.

The first pass uses ablation to vaporize the tissue and create micro-channels of injury.
The second pass uses coagulation to deliver a thermal injury to the area, which further stimulates the body’s normal wound healing process.
Minimal Downtime

Juliet provides a gentle treatment resulting in minimal downtime and a quick recovery.

Juliet Skin Rejuvenation Handpiece

Juliet provides comprehensive treatment options.

The MicroSpot handpiece is specially designed for skin resurfacing. The system-integrated smoke evacuator attaches to the Microspot handpiece to control and manage plume distribution for greater safety for the provider and patient.
Indicated Uses

Skin resurfacing
Periorbital wrinkles
Perioral wrinkles
Lentigines
Café-au-lait spots
Becker naevi
Naevi Spili
Epidermal naevi
Xanthelasmas
Syringomas
Adenoma sebaceum
Milia palpebrarum
Actinic keratoses
Seborrhoic keratoses
Morbus Favre-Racouchot
Treatment Parameters – Aesthetic Skin Treatments

The following parameters are provided as a guide only and are based on practitioner feedback. Start with conservative settings and observe laser-tissue interaction and clinical endpoints to determine appropriate settings. Adjust settings based on tissue response.

Light Peel (Conservative Treatment)

Skin Types: I-VI

Indication: Induces a light peel to improve photo damage and skin tone with minimal downtime.

Handpiece: MicroSpot

Treatment Mode: C 10% – All Skin Types

Fluence: 4 J/cm2

Interval: 0.0 s

Treatment Technique: Circular Painting Technique with handpiece distance gauge in light contact with skin. Treat each postcard sized area with 1 pass.

Treatment Interval: Every 2 weeks

Ablative Treatment (Moderate to Aggressive Treatment)

Skin Types: I-V

Indication: Resurfacing treatment to improve benign pigmented lesions. photo damage. Fine lines, wrinkles and acne scars

Handpiece: MicroSpot

Treatment Mode & Fluence:

N 10%: Skin Types 1-111L.e ss ablation per pulse. more thermal effect.

E 10%. Skin Types 1-V. Deeper ablation per pulse. less thermal effect.

N10%· 5 – 10 J/cm’ (Initial Passes)

N10%. 5 J/cm2 (Final Pass)

Or

E10%· 10 -40 J/cm2 (Initial Passes) 1.0

E10%. 10 J/cm2 (Final Pass) 6.0

Interval: according to user’s experience

Treatment Technique: 1-2 Passes – Single spot with 0-50%/overlap

Final Pass – Circular Painting Technique with handpiece distance gauge in light contact with skin to randomize pattern.

Scars or deep wrinkles may require additional passes or treatments.

Follow with micro Genesis treatment if desired.

Treatment Interval: Every 4 weeks

micro Genesis (Conservative or Moderate)

Skin Type: I-VI

Indication: Increases elasticity of tissue due to neocollagenesis.

Handpiece: MicroSpot

Treatment Mode: W 25%

Fluence: 4 J/cm2

Interval: 0.0 s

Treatment Technique: Circular Painting Technique with handpiece pulled away from skin (non-contact).

Skin Types 1-111: 4 – 6 inches from skin

Skin Types IV-VI: 6 – 10 inches from skin

Treat postcard sized areas on the face for 1-2 minutes in each area.

• Forehead • Penorbital • 1st cheek/Jawline • 2nd cheek Jawline • Penoral/Nasal

Treatment Interval: Every 2 weeks

MANUFACTURER NOTES – for Vaginal Rejuvenation

Erbium:YAG laser: the best option for intravaginal treatments

The Juliet laser treatment improves women gynecological health thanks to a minimally invasive treatment whose goal is the stimulation of new collagen and elastin production, along with an improved vascularization of the vaginal mucosa.

The procedure is performed by using the MCL31 Dermablate laser by Asclepion, a best selling laser worldwide in the field of aesthetic medicine. Similarly to the procedure used for facial rejuvenation, the Juliet laser treatment uses light energy to gently deliver energy to the tissue and stimulate it to produce new collagen.

Newly designed, single use STERI-SPOT handpiece

The specially designed STERI-SPOT handpiece allows for an easy insertion and for a very intuitive use and handling. It is delivered in single, sterile packages and is intended for single use only, guaranteeing you the maximum hygiene.

MicroSpot optic for gentle and more effective treatments

The STERI-SPOT handpiece features a patended MicroSpot optic with a squared spot of 9 x 9 mm, consisting of 169 MicroSpots. This optic allows the selective treatment of only “fractions” of the tissue in the form of a grid, made possible by splitting the laser beam into several hundred partial rays.

This triggers skin renewal and collagen formation with rapid wound healing, which is supported by the untreated skin and therefore involves a very low risk of side effects.

Rediscover the secret of your femininity

The effective, cutting-edge, hormone-free treatment concept for the MCL31 Dermablate for vulvovaginal conditions: Atrophy, Stress Urinary Incontinence and Tightening.

The newly designed Steri-Spot Handpiece combined with the latest Er:YAG technology allows fast and painless treatments, with no need for anesthesia or downtime.
