GSSI UtilityScan Pro GPR For Sale with a Best Price

GSSI UtilityScan Pro GPR For Sale with a Best Price Both metallic and non-metallic objects, such as PVC pipes and underground storage tanks, as well as utilities like gas, communications, and sewage lines, can be easily identified and their positions and depths marked. The UtilityScan Pro, which is based on the SIR 4000 controller, gives GPR experts answers for any subterranean location scenario.

Fully Customizable System
The UtilityScan Pro offers a variety of antenna configurations and cart options for users to personalize. The customized solutions fit a variety of utility locating applications and offer survey flexibility, from well-prepared, smooth surfaces to rough terrain with our sturdy four-wheel cart.

The UtilityScan Pro delivers exceptional data quality and is rugged enough to withstand the job site’s toughest conditions. Locate subsurface utilities with confidence.

GSSI Utility Scan Pro GPR  Spesifications

• System: SIR 4000
• Antennas: Compatible with all GSSI antennas
• Number of Channels: Records data from 1 single-frequency antenna or 1 dual-frequency antenna
• Data Storage: 32 GB Flash, 1 GB RAM
• Display: 10.4” LED
• GPS: Data logged internally
• Display Modes: Linescan, Full 3D
• Environmental Rating: P64
• Data Acquisition
  • Data Format: RADAN® (dzt)
  • Output Data Format: 32-bit
  • Scan Inverval: User-selectable, up to 4000 scans/sec
  • Number of samples per scan: 256, 512, 1024, 2048, 4096, 8192, 16384
  • Operatiing Modes: Continuous (time) or survey wheel (distance triggered) or point mode
  • Time Range: 0-20,000 nanoseconds full scale, user-selectable Gain: manual adjustment from -42 to +126 dB Number of segments in gain curve is user-selectable from 1 to 8
  • Standard Real-Time Filters: Infinite Impulse Response (IIR) – Low and High Pass, vertical and horizontal – Finite Impulse Response (FIR) – Low and High Pass, vertical and horizontal
  • Advanced Real-Time Filters: Migration, Surface Position Tracking, Signal Noise Floor Tracking, Adaptive Background Removal
  • Automactics System Setups: Storage of an unlimited number of system setup files for different survey conditions and/or antenna deployment configurations
  • Automatic Antenna Recognition: Automatic recognition of Smart Antennas to allow maximum compliant transmit rate
  • Languanges: English, Chinese, Japanese and French
• Operating
  • Operating Temperature: -20°C to 40°C (-4°F to 104°F)
  • Batttery: Inspired Energy Ni2040ED, 3 hour runtime (battery life dependent on level of display brightness)
  • Transmit Rate: Up to 800 KHz (International) US/Canada and CE rates depend on antenna model
• Input/Output
  • Available Ports: Analog and Digital, RS232, HDMI, Ethernet to PC, USB 2.0 port and mini USB
  • Ethernet: RJ45 100BT Ethernet
  • Usb Host: Usb host with external keyboard support, USB flash drive support and Usb hub support
• Mechanical
  • Dimensions: 14x10x2.75 in (36x25x7 cm)
  • Weight: 10 lbs (4.53 kg) including battery
  • Relative Humidity: <95% non-condensing
  • Storage Temperature: -40°C to 60°C (-40°F to 140°F)

 GSSI Utility Scan Pro GPR  package includes

• SIR 4000 Control Unit, 400 MHz, 300/800 DF, or 350 HS Antenna
• 3-wheel or 4-wheel cart
• 2 m control cable
• SIR 4000 sunshade
• SIR 4000 AC/DC power supply
• 2x Lithium-ion battery, Dual-bay battery charger
• Transit case
• 2-year warranty
• RADAN 7 for UtilityScan, RADAN 7
• LineTrac
• 2 Year Warranty
