SATIR D300 Thermal imager camera For Sale With a Best Price is a newly designed performance thermography camera based on the D300 Mid-Level Model. While the D600’s 640×480 infrared detector performs better than the D300’s, it nevertheless has many of the same functions. The 640×480 infrared detector produces 307,200 potent pixels, enabling us to produce high-quality images and videos.
The D300 features an easy-to-use touchscreen interface that combines flawlessly with Duo Vision Plus to provide effortless auto-focusing. Professionals with varying levels of experience can attain ideal outcomes with the help of this blend of sophisticated features and an intuitive design.
Key Features
– Digital Zoom
– IR/ Digital/Duo-Vision/Duo Vision Plus
– Laser Pointer
– 8 Hours Battery Life
– Adaptable LCD Display
– Easy to use interface
– 10MP High Definition Camera
– Thermal Video Recording
| Image Performance | |
| Detector Resolution | 384×288 |
| Super Resolution | Support,768×576 |
| Thermal Sensitivity (N.E.T.D) | ≤0.03°C@30°C |
| Spatial Resolution | 1.13 mRad |
| Field of View (F.O.V) | 24°x18° |
| Spectral range | 7.5~14μm |
| Focus Mechanism | Manual/Motor/Auto |
| Measurement | |
| Temperature Range | -20°C ~ + 650°C, up to +1500°C (Optional) |
| Accuracy | ±1°C or ± 1% of readings (-20°C ~ + 150°C) ±2°C or ± 2% of readings |
| Image Presentation | |
| Image Mode | IR/ CCD /Duo-Vision/Duo-Vision Plus/ PIP |
| Visible Pixels | HD 10MP Digital Camera |
| LCD Display | 3.5” Capacitive Touch Screen |
| Frame Rate | 50Hz /60 Hz |
| Digital Zoom | 1x to 10x, continuous |
| Colour Palettes | 10 Palettes |
| Measurement Tools | 10 moveable spot, Alarm, Auto hot/cold, 5 line profile, 10 areas box, centre spot,isoterm |
| Alarm | Alarm Yes, auto (above, below, equal) |
| File Format (Thermal/Visual) | JPG |
| Laser | |
| Laser Type | Class 2, 1mW/635nm, red |
| Laser Ranging | Yes |
| Measurement Range | 0.05m—30m |
| Environmental | |
| Encapsulation | IP54 |
| Shock/Vibration Resistance | 25G/2G |
| Operating Temperature | -20°C ~ +50°C |
| Physical Characteristics (Camera Body) | |
| Weight | 1.1Kg (including batteries) |
| Dimensions | 232mm×115mm×168mm |
| Additional Features | |
| Battery | Lithium-ion battery, 3.7V, 9000mAh |
| Battery Life | ≥5 hours (normal temperature) |
| Charging | Type-C 5V |
| Video Record | Yes, non-radiometric and radiometric video |
| Bluetooth | Yes |
| WIFI | Yes |
| GPS | Yes |
| QR Code Scan | Yes |
| Wireless Screen Projection | Yes |
| Optional Lens | 7/12/48 deg lens |
