Creaform HandySCAN 700 Elite 3D Scanner For Sale with a Best Priceis a top-notch solution with a comprehensive, business-grade software bundle. It is a high-end, portable 3D scanner manufactured by Canadian leader Creaform. 2014 saw its initial release. The SILVER Series features blue lasers as of 2022, as opposed to red ones.
Creaform HandySCAN 700 Elite 3D Scanner For Sale with a Best Price In the “Cross grid” mode, it projects seven blue laser crosses, and in the “Single beam” mode, it projects one blue laser beam in order to catch intricate features and deep pockets.
INCLUDES:
(1X) HandySCAN 700 3D Scanner
(1X) External Battery
(1X) Power supply
(1X) 2,000 positioning targets
(1X) Magnetic, reusable positioning targets
(1X) Carrying case
(1X) Calibration plate
(1X) Custom USB cable
(1X) One-Year warranty on parts and labor
(1X) One USB key holding the VXElements software suite
(1X) License key
Specifications
| Accuracy | Up to 0.030 mm (0.0012 in) |
| Volumetric accuracy | 0.020 mm + 0.060 mm/m (0.0008 in + 0.0007 in/ft) |
| Volumetric accuracy with MaxSHOT Next |Elite | 0.020 mm + 0.015 mm/m (0.0008 in + 0.00018 in/ft) |
| Measurement resolution | 0.050 mm (0.0019 in) |
| Mesh resolution | 0.200 mm (0.0078 in) |
| Measurement rate | 480,000 measurements/s |
| Light source | 7 blue laser crosses (+ 1 extra line) |
| Laser class | 2M (eye-safe) |
| Scanning area | 275 x 250 mm (10.8 x 9.8 in) |
| Stand-off distance | 300 mm (11.8 in) |
| Depth of field | 250 mm (9.8 in) |
| Part size range | 0.1–4 m (0.3–13 ft) |
| Software | VXelements |
| Output formats | .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf |
| Compatible software | 3D Systems (Geomagic® Solutions), InnovMetric Software (PolyWorks), Metrologic Group (Metrolog X4), New River Kinematics (Spatial Analyzer), Verisurf, Dassault Systèmes (CATIA V5, SOLIDWORKS), PTC (Creo), Siemens (NX, Solid Edge), Autodesk (Inventor, PowerINSPECT) |
| Weight | 0.85 kg (1.9 lb) |
| Dimensions (LxWxH) | 77 x 122 x 294 mm (3.0 x 4.8 x 11.6 in) |
| Connection standard | 1 X USB 3.0 |
| Operating temperature range | 5-40 °C (41-104 °F) |
| Operating humidity range | 10-90% |
| Certifications | EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive), compatible with rechargeable batteries (when applicable), IP50, WEEE |
| Patents | CA 2,600,926, CN 200680014069.3, US 7,912,673, CA 2,656,163, EP (FR, UK, DE) 1,877,726, AU 2006222458, US 8,032,327, JP 4,871,352, US 8,140,295, EP (FR, UK, DE) 2,278,271, EP (FR, UK, DE) 2,230,482, in 266,573, US 7,487,063, CA 2,529,044, EP (FR, UK, DE) 3,102,908, US 15/114,563, CN 201580007340X |
