Artec Scanner EVA Lite Handheld 3D Scanner For Sale with a Best Price Include Manual & Software, Online Training After Sell
Real-time capture is possible with the handheld, flexible Artec Eva 3D scanner. You must move the scanner around an object to record it from various angles in order to accomplish this. Up to 16 scans can be captured per second by the Artec Eva. You can see the areas you have already scanned in the Artec Studio scanning program because of real-time registration. It functions in a manner akin to a video camera. But instead of recording 2D photos, you capture the object’s three-dimensional surface. Align the scans and combine them all to create a full 3D model. For additional processing, a number of methods are provided, including adaptive data reduction and hole filling.
specifications:
* Ability to capture texture No
* 3D resolution, up to 0.5 mm
* 3D point accuracy, up to 0.1 mm
* 3D accuracy over distance, up to 0.15% bei 100 cm
* Texture resolution –
* Colors 24 bpp
* Light source flash bulb (no laser)
* Working distance 0.4 – 1 m
* Linear field of view, HxW @ closest range 214 x 148 mm
* Linear field of view, HxW @ furthest range 536 x 371 mm
* Angular field of view, H?W 30 x 21°
* Video frame rate, up to 16 fps
* Exposure time 0.0002 s
* Data acquisition speed, up to 2 000 000 points/s
* Multi core processing Yes
* Dimensions, HxDxW 261.5 x 158.2 x 63.7 mm
* Weight 0.85 kg / 1.9 lb
* Power consumption 12V, 48W
* Interface 1? USB2.0
* Output formats OBJ, PTX, STL, WRML, ASCII, AOP, CSV, PLY
* Processing capacity 40’000’000 triangles/1GB RAM
* Supported OS Windows Vista x64. Windows 7 x64
* Minimum computer requirements I5 or I7 recommended, 8GB RAM, NVIDIA GeForce 400 series
* Calibration no special equipment required
Would you like to swiftly scan medium-sized objects without having to spend time placing reference marks? The Artec Eva 3D scanner is the ideal choice in that case! Artec’s optical scanner allows you to quickly and accurately capture small to medium-sized objects with excellent quality. Setting up or attaching reference markers to the object is not necessary because the Artec scanner Eva scans objects in real time and combines the various measurements into a 3D representation.
Usability:
Real-time capture is possible with the handheld, flexible Artec Eva 3D scanner. You must move the scanner around an object to record it from various angles in order to accomplish this. Up to 16 scans can be captured per second by the Artec Eva. You can see the areas you have already scanned in the Artec Studio scanning program because of real-time registration. It functions in a manner akin to a video camera. But instead of recording 2D photos, you capture the object’s three-dimensional surface. Align the scans and combine them all to create a full 3D model. For additional processing, a number of methods are provided, including adaptive data reduction and hole filling.
Attention:
Unsupported operating systems: Windows XP, Windows Vista, 32-bit OS, AMD FirePro M6100 Fire GL V
Not recommended: Xeon or AMD processors, NVIDIA SLI or AMD CrossFire configuration
NVIDIA Quadro and Intel cards are officially supported starting with Artec 11
Compatible software and export formats:
Geomagic
RapidForm
RHINO
Autodesk Maya
3D Max
AutoCAD
blenders
XSI
mud box
Pixologic ZBrush and others
Export formats: AOP, STL, OBJ, PLY, VRML, ASCII, E57, PTX and others.
