Easy Laser XT550 – Ex/ATEX Laser Shaft alignment System is designed to be used in dangerous environments and is simple to use with the XT Alignment app. This sophisticated measurement device checks soft foot, bearing play, base twist, and alignment of rotating machinery that is horizontal, vertical, or flange mounted. It also automatically records the data and can optionally attach digital images.
With the device, you can measure huge machinery and lengthy spans thanks to Easy-Laser’s dot laser technology. The measuring units are classified as IP66 and IP67 water and dust proof, and they have been authorized in compliance with the most recent ATEX directive .
Choose your own display unit
System XT550 comes in two configurations; with or without the ATEX approved ecom Tab-Ex® display unit. The XT Alignment app runs on most iOS and Android units, as well as our own XT display unit. However, those are not allowed in potentially explosive areas, but makes for a perfect complement for use in other places.
Easy Laser XT550 – Ex/ATEX Laser Shaft alignment System Includes:
- ecom Tab-Ex® Display (Ex)
- XT50-M Measuring Unit (Ex)
- XT50-S Measuring Unit (Ex)
- Shaft brackets w/ chains and rods (x2)
- 60mm Rods (x4)
- 100mm Rods (x2)
- 900mm Extension chains (x2)
- 10ft Measuring Tape
- Rod Tool
- 100-240VAC Charger
- DC split cable for charging
- Quick reference manual
- Cleaning cloth for optics
- USB memory with manuals
- Ex/ATEX Carry case
Easy Laser XT550 – Ex/ATEX Laser Shaft alignment System Technical data
Display Unit
- Name
- ecom Tab-Ex® 3
- Type of display/size
- TFT 8″ colour screen
- Operating temperature
- -20–55 °C
- Communication
- Bluetooth® 5.0 Wireless technology, WiFi
- Camera
- 13 Mp with flash (rear), 5 Mp (front)
- Dimensions
- WxHxD: 263x162x26 mm [10.3×6.4×1.0″]
- Weight (without batteries)
- 1100 g [2.42 lbs]
- Operating time
- Up to 11 h continuously
- Operating system
- Android™
- ATEX/UKCA Ex classification
- II 2G Ex db ia IIC T6 Gb IP64
II 2D Ex ia tb IIIC T80°C Db
-20°C ≤ Ta ≤ +55 °C - IECEx classification
- Ex db ia IIC T6 Gb IP64
Ex ia tb IIIC T80°C Db
-20°C ≤ Ta ≤ +55°C - Ex certificate number
- EPS 22 ATEX 1055X, IECEx EPS 22.0014X, EPS 22 UKEX 1055X
Measuring Units
- Name
- XT50-M / XT50-S
- Communication
- BT wireless technology
- Type of detector
- 1 axis TruePSD 20×20 mm [0.79×0.79″]
- Resolution
- 0.001 mm [0.05 mils]
- Measurement accuracy
- ±1µm ±1%
- Measurement range
- Up to 20 m [66 feet]
- Type of laser
- Diode laser
- Laser wavelength
- 630-680 nm
- Laser class
- Safety class 2
- Laser output
- <1 mW
- Electronic inclinometer
- 0.1° resolution
- Environmental protection
- IP class 66 and 67
- Operating temperature
- -10–50 °C
- Storage temperature
- -20–50 °C
- Relative humidity
- 10–95%
- Housing material
- Anodized aluminium + PC/ABS + TPE
- Dimensions
- WxHxD: 76×76.5×50.9 mm [3.0×3.0x2.0″]
- Weight
- 316 g [11.1 oz]
- OLED display
- 128×64 pixels
- Operating time
- Up to 20 h continuously
- Ex classification
- II 2 G Ex ib op is IIC T4 Gb, -10°C ≤ Ta ≤ +50°C
II 2 D Ex ib op is IIIC T135°C Db, -10°C ≤ Ta ≤ +50°C - Ex certificate number
- Presafe 17 ATEX 10552X, IECEx PRE 17.0049X
