Easy Laser XT770 Shaft Alignment System For Sale with a Best Price

Easy Laser XT770 Shaft Alignment System For Sale with a Best Price is a shaft alignment system using two dots of laser. The display unit of the Easy-Laser® XT770 is an Android or iOS tablet or phone.

The dot laser technique is employed by the XT770 measurement instruments. Compared to line laser systems, this allows for the measurement of larger machines and greater spans. In the event that the connection has backlash, it also offers increased precision. Furthermore, the dot laser makes it possible to verify additional factors during machine installation, such as bearing clearance and foundation twist.

You can choose between multiple measuring methods with the XT770, such as multipoint and continuous sweep. This provides you with the adaptability required to obtain the ideal measurement outcome.

The XT products are dust- and water-resistant, with ratings of IP66 and IP67. This, along with extended operating hours, ensures that you may start and complete even the most difficult tasks.

The most potent alignment system in our Generation XT lineup is the Easy-Laser® XT770. It enables you to view alignment data on various handheld devices, such as our own ergonomic, durable, IP66/67-approved, shock-proof alignment computer, the Easy-Laser® XT11, which has an integrated 13MP camera for documentation and HDMI video output.

The Easy-Laser XT770 allows you to measure twist of foundation, soft foot, bearing clearance, and more. It can also be used to align an infinite number of machine trains and laser shaft alignment of horizontal and vertically/flange mounted machines. You may monitor machine movement over time with the EasyTrend application. That is helpful, among other things, for inspecting pipes for strain problems and heat expansion.

Your machine may be adjusted simultaneously in both vertical and horizontal directions, with measurement units in any location, thanks to 2-axis PSDs (position sensitive detectors). Adjusting 360° Live is what we call it. The Easy-Laser XT measuring devices and display unit are classified as IP66 and IP67 water and dustproof, and they are also shockproof. The Pump laser alignment tool’s extended operating times ensure that you can take on and complete even the most difficult tasks.

The XT770 offers you the same freedom to choose between hardware platforms and execute laser shaft alignment with ease and accuracy as our Easy-Laser® XT440 and XT660. Devices running AndroidTM and Apple® iOS can both use the Easy-Laser® XT Alignment application. All features are included in a single app that includes pump laser programs.

Top Features:

• Advanced capabilities such as coupled and uncoupled continuous sweep plus multi-point measurement modes.
• 360Live feature allows for adjustment with units positioned at any angle around the shaft
• Program for Machine Trains (unlimited)
• Program and hardware for Twist/Flatness base measurement
• Built-in ANSI/ASA Shaft Alignment Tolerances
• Alignment data can be stored in the XT application, USB drive, or emailed directly as a PDF report including measurement data, color images, and signature.
• Track machine movement over time with EASYTREND (optional DM-brackets required).
• Cardan shaft alignment (optional cardan bracket required)
• Intuitive user interface guides you through the measurement process
• Purchase multiple systems with various capabilities, train just once! The training costs are minimized significantly since the App interface and basic functionality is identical across all systems (XT660 / XT440 / XT190).

Options:

• System with or without alignment computer
• On-board IR camera option for XT11 display unit —measure heat profiles before and after alignment!
• Vibration monitoring and analysis with optional Easy-Laser® XT280 VIBROMETER
• Align belt and chain drives with optional Easy-Laser® XT190 BTA hardware
• Precision machine base leveling with optional Easy-Laser® XT290
• Flatness and straightness measurements with optional GEO kit

This Easy-Laser XT770 includes:

• • 1 Measuring unit XT70-M IP66/67, 66ft measurement range, up to 24 hour operating time
  • 1 Measuring unit XT70-S IP66/67, 66ft measurement range, up to 24 hour operating time
  • 2 Shaft brackets with chains and rods 120 mm [4.72″]
  • 2 12-1147 magnetic shaft brackets
  • 4 Rods 60 mm [2.36″]
  • 4 Rods 120 mm [4.72″]
  • 2 Magnet bases
  • 2 Offset brackets
  • 2 Extension chain 900 mm [35.4″]
  • 1 Measuring tape 3 m [9.8′]
  • 1 Hexagon wrench set
  • 1 Charger (100–240 V AC)
  • 1 DC split cable for charging
  • 1 DC to USB adapter, for charging
  • 1 Quick reference manual
  • 1 Cleaning cloth for optics
  • 1 USB memory with manuals
  • 1 Documentation folder
  • 1 Carrying case Large
