Skyray Explorer 7000 Series Handheld X-ray Scanner Minerals Spectrometer Analyzer Our best and most sophisticated handheld XRF is the 5th generation Explorer Handheld X-Ray Fluorescence Spectrometer from Skyray Instruments. The portability and handheld size factor of a handheld XRF combines with the performance and accuracy of a desktop X-ray fluorescence spectrometer. With its wider application range, great stability, lower detection limits, and more advanced digital multi-channel technology, EXPLORER is an instrument that can be used for almost any XRF application.
With the latest intelligent software from Skyray, the Explorer XRF handheld X-ray fluorescence spectrophotometer is as simple to use as your regular appliances. Now that the instrument has been designed with user engagement and operation in mind, the majority of users can pick it up in a matter of minutes. The software Skyray Intellectualized is utilized in all application modes. A single Explorer XRF can be configured with up to 5 software databases, covering mineral, alloy, and soil analyses as well as RoHS and mineral analysis.One Explorer XRF can replace up to five rival handheld XRFs thanks to its simple, modern style, one-click testing, and simple database changeover.
Program Choices
Software for Risky Substances: RoHS
Software for Alloy Analysis; Heavy Metals in Soil; Mineral Analysis; Precious Metals Software Thickness Plating Softwar
Features
Fast measurement with results in three seconds, along with nondestructive detection that happens quickly.
Accuracy levels of the Fast SDD Detector are comparable to those of desktop XRF systems.
During testing, the integrated GPS logs latitude, longitude, and altitude.
Explorer XRF’s waterproof and dustproof design allows it to be used continually in challenging settings.
Mini-USB, Bluetooth, and an expandable SD card for PC connectivity and data storage
On request, customers can add and change customized workcurves.
Dual test mode for recognizing light and regular elements in a single test, auto-collimator switching, and light elements detection without the need for helium gas
High quality 5 megapixel camera integrated for in-the-moment sample observation.
| Specifications | |
|---|---|
| Measurable elements: | Magnesium(Mg) to Uranium (U) |
| Limits of Detection | 1 ppm |
| Analysis Range: | 1 ppm-99.999% |
| Test time | 2 second results, average test time 20 seconds, testing can be set by user from 5 to 60 seconds |
| Battery: | 9000mAh rechargeable lithium battery-up to 12 hours work time |
| Energy Resolution | 128eV |
| Detector | Fast SDD |
| Sample types | Solids, liquids, powders |
| System Parameters | GPS, WIFI, Bluetooth, SPI data transmission, waterproof mini USB, 1G CPU, system memory-1G, SD Card-4G test storage data, expandable to 32G. |
| Weight: | 1.5 kg |
