Faro Focus X130 Laser Scanner For Sale with a Best Price is among the greatest in its class that we have ever seen. FARO has lifted the bar considerably with two new models, the X130 and the X330, which are upgrades from earlier models that didn’t quite make our list of the top 3D scanners in their respective price groups last year. This review will concentrate on the X130 scanner, which is one of the most flexible in its class due to its wide range of real-world applications. It is also reasonably priced when compared to other scanners that have similar capabilities and output quality.
All widely used software programs for forensics, industrial manufacturing, architecture, civil engineering, construction, accident reconstruction, and industrial manufacturing can readily import the 3D scan data. The laser scanner also has a great degree of versatility and endurance, with a 4.5-hour battery life. The Focus is a genuinely portable scanner because to its compact size, low weight, and SD card.
The robust and reasonably priced solution for mid-range 3D documentation applications is the new FARO Focus3D X 130. It is a versatile instrument for a variety of working environments due to its one million points/second scanning rate, ease of use, portability, scanning range of up to 130 meters, integrated GPS, extremely low noise, and WLAN remote control.
Key Benefits
scanning at midrange, up to 130 meters
The Focus3D X 130’s 130-meter range enables laser scanning for a wide range of applications in building, process, architecture, BIM, forensics, shipbuilding, and computer graphics, among many other fields.
GPS receiver integrated into Xtra Positioning
Determine the scanner’s position with ease. This gives the precise time and place of the user’s scans and facilitates the registration procedure.
Xtra portable
The Focus3D X 130 weighs only 5.2 kg and is only 24 x 20 x 10 cm. It is genuinely portable thanks to its waterproof Pelicase and comfortable backpack with a tripod holder.
With a wireless LAN remote control, you may watch scans and start and stop the machine from a distance.
greatest financial value
The new Focus3D X 130 is a first-to-market product that offers exceptional performance at competitive prices.
Key Features
Ranging unit
Unambiguity interval: >130m
Range Focus3D X 130: 0.6m – 130m indoor or outdoor with upright incidence to a 90% reflective surface
Measurement speed (pts/sec): 122,000 / 244,000 / 488,000 / 976,000
Ranging error1: ±2mm
Colour unit
Resolution: Up to 70 megapixel colour
Dynamic colour feature: Automatic adaption of brightness
Parallax: Co-axial design
Deflection unit
Field of view (vertical/horizontal): 300° / 360°
Step size (vertical/horizontal): 0.009° (40,960 3D-Pixel on 360°) / 0,009° (40.960 3D-Pixel on 360°)
Max. vertical scan speed: 5.820rpm or 97Hz
Laser (optical transmitter)
Laser class: Laser class 1
Wavelength: 1550nm
Beam divergence: Typical 0.19mrad (0,011°) (1/e, halfangle)
Beam diameter at exit: Typical 2.25mm (1/e)
Data handling and control
Data storage: SD, SDHC, SDXC; 32GB card included
Scanner control: Via touchscreen display and WLAN
New WLAN access: Remote control, scan visualisation are possible on mobile devices with Flash®
Multi-Sensor
Dual axis compensator: Levels each scan: Accuracy 0.015°; Range ± 5°
Height sensor: Via an electronic barometer the height relative to a fixed point can be detected and added to a scan.
Compass4: The electronic compass gives the scan an orientation. A calibration feature is included.
GPS: Integrated GPS receiver
Power supply voltage: 19V (external supply) / 14.4V (internal battery)
Power consumption: 40W and 80W (while battery charges)
Battery life: 4.5 hours
Ambient temperature: 5° – 40°C
Humidity: Non-condensing
Cable connector: Located in scanner mount
Weight: 5.2kg
Size: 240 x 200 x 100mm
Maintenance / calibration: Annual
