Fluke Ti480 PRO Infrared Camera For Sale with a Best Priceis a rugged and superbly engineered 640 x 480 9Hz thermal imaging camera. Users can now perform thermal imaging inspections with more confidence and faster results than ever before – all with the ruggedness and ease of use expected from Fluke.
The Ti480 offers multiple features to optimise focus and ensure that you get more accurate temperature information. MultiSharp™ Focus delivers images automatically focused throughout the field of view even if you start from a completely blurry target. The camera takes multiple images and combines them to give you clear, accurate focus on targets near and far. Simply point and shoot.
Features
- Increased sensitivity to visualize temperature differences
- Easier to visualize and diagnose issues with sharper onscreen images, multiple rectangle markers and nine color palettes
- More intuitive visual interface, improved, user-tested, touch screen interface
- More flexibility to visualize target, tiny-to-large with interchangeable smart lenses – no calibration required, 2x and 4x telephoto, wide angle and macro lens compatibility
- Capture a clear, accurate image focused throughout the field of view with MultiSharp™ Focus
- Get an instant in-focus image of your designated target. LaserSharp® Auto Focus uses a built-in laser distance meter that calculates and displays the distance from your designated target
- Get 4x the pixel data with SuperResolution, which captures multiple images and combines them to create a 1280 x 960 image
- Save time – wirelessly sync images directly from your camera to the Fluke Connect® system, and attach to an asset record or work order
- Reduce the need take notes in the field with IR-PhotoNotes™ and voice annotations
Applications
- Industrial maintenance
- Heavy commercial facility maintenance
- Oil and gas maintenance
- Veterinary
- Reliability inspections (PdM)
- Heavy building diagnostics – building envelope and construction defects
- Electrical, water, gas utilities
- Chemical processing
- Machinery, instrumentation and appliances
Fluke Ti480 PRO Infrared Camera Specifications :
| IFOV with standard lens (spatial resolution) | 0.93 mRad, D:S 1065:1. | ||
| Detector resolution | 640 x 480 (307,200 pixels) or 1280 x 960 with SuperResolution. | ||
| SuperResolution | Yes, on camera and in software. Captures and combines 4x the data to create a 1280 x 960 image. | ||
| MultiSharp™ Focus | Yes, focused near and far, throughout the field of view. | ||
| LaserSharp® Auto Focus | Yes, for consistently in-focus images. Every. Single. Time. | ||
| Laser distance meter | Yes, calculates distance to the target for precisely focused images and displays distance on screen. | ||
| Advanced manual focus | Yes. | ||
| Ruggedized touchscreen display | 3.5 inch (landscape) 640 x 480 LCD. | ||
| Rugged, ergonomic design for one-handed use | Yes. | ||
| Digital zoom | 2x and 4x. | ||
| Pre-calibrated Lenses | wide angle, 2x telephoto, 4x telephoto and 25 micron/macro. | ||
| Temperature measurement | |||
| Temperature measurement range (not calibrated below -10 °C) | ≤ -20 °C to +800 °C (-4 °F to 1472 °F). | ||
| Accuracy | ±2 °C or 2% (at 25 °C nominal, whichever is greater). | ||
| Thermal sensitivity (NETD)* | ≤ 0.05 °C at 30 °C target temp (50 mK). | ||
| On-screen emissivity correction | Yes (both value and table). | ||
| On-screen reflected background temperature compensation | Yes. | ||
| On-screen transmission correction | Yes. | ||
| Live line marker | Yes. | ||
| *Best possible. | |||
| Wireless connectivity | |||
| To PC, iPhone® and iPad® (iOS 4s and later), Android™ 4.3 and up, and WiFi to LAN (where available). | |||
| Fluke Connect® app compatible | Yes, connect your camera to your smartphone, and images taken automatically upload to the Fluke Connect app for saving and sharing. | ||
| Fluke Connect Assets optional software | Yes, assign images to assets and create work orders. Easily compare measurement types – whether mechanical, electrical or infrared images – in one location. | ||
| Fluke Connect Instant Upload | Yes, connect your camera to your building’s WiFi network, and images taken automatically upload to the Fluke Connect system for viewing on your smartphone or PC. | ||
| Fluke Connect tool compatible | Yes, connects wirelessly to select Fluke Connect enabled tools and displays measurements on camera screen. Five simultaneous connections supported. | ||
| Fluke Connect SmartView desktop software | Yes. | ||
| IR-Fusion® technology | |||
| Adds the context of the visible details to your infrared image. | |||
| AutoBlend™ mode | Min, Mid, Max IR plus full visible on camera; continously variable in software. | ||
| Picture-In-Picture (PIP) | Yes. | ||
| Built-in digital camera (visible light) | 5 MP. | ||
| Lenses | |||
| Standard lens | IFOV (spatial resolution) | 0.93 mRad, D:S 1065:1. | |
| Field of view | 34 °H x 24 °V. | ||
| Minimum focus distance | 15 cm (approx. 6 in). | ||
| IR-Fusion® technology | Picture-in-picture and full screen. | ||
| Optional 2x telephoto smart lens | IFOV | 0.46 mRad. D:S is 2145.1. | |
| Field of view | 17 °H x 12 °V. | ||
| Minimum focus distance | 45 cm (approx. 18 in). | ||
| IR-Fusion® technology | Picture-in-picture and full screen. | ||
| Optional wide-angle smart lens | IFOV | 1.85 mRad. D:S is 525:1. | |
| Field of view | 68 °H x 48 °V. | ||
| Minimum focus distance | 15 cm (approx. 6 in). | ||
| IR-Fusion® technology | Full screen. | ||
| Level and Span | |||
| Fast auto toggle between manual and auto modes | Yes. | ||
| Fast auto-rescale in manual mode | Yes. | ||
| Minimum span (in manual mode) | 2.0 °C (3.6 °F). | ||
| Minimum span (in auto mode) | 3.0 °C (5.4 °F). | ||
| Data storage and image capture | |||
| Extensive memory options | Removable 4 GB micro SD memory card, 4 GB internal flash memory, save to USB flash drive capability, upload to Fluke Cloud™ for permanent storage. | ||
| Image capture, review, save mechanism | One-handed image capture,review, and save capability. | ||
| Image file formats | Non-radiometric (.bmp) or (.jpeg) or fully-radiometric (.is2); no analysis software required for non-radiometric (.bmp, .jpg and .avi) files. | ||
| Memory review | Thumbnail and fullscreen review. | ||
| Software | Fluke Connect SmartView software – full analysis and reporting software and Fluke Connect system. | ||
| Export file formats with Fluke Connect SmartView software | Bitmap (.bmp), GIF, JPEG, PNG, TIFF. | ||
| Voice annotation | 60 seconds maximum recording time per image; reviewable playback on camera, optional bluetooth headset available but not required. | ||
| IR-PhotoNotes™ | Yes (5 images). | ||
| Text annotation | Yes. | ||
| Video recording | Standard and radiometric. | ||
| File formats video | Non-radiometric (MPEG – encoded .AVI) and fully-radiometric (.IS3). | ||
| Remote display viewing | Yes, see the live stream of the camera display on your PC, smartphone, or TV monitor. Via USB, WiFi hotspot, or WiFi network to Fluke Connect SmartView software on a PC; via WiFi hotspot to the Fluke Connect app on a smartphone; or via HDMI to a TV monitor. | ||
| Remote control operation | Yes, through Fluke Connect SmartView software or Fluke Connect mobile app. | ||
| Auto capture (temperature and interval) | Yes. | ||
| Battery | |||
| Batteries (field-replaceable, rechargeable) | Two lithium ion smart battery packs with five-segment LED display to show charge level. | ||
| Battery life | 2-3 hours per battery (Actual life varies depending on settings and usage). | ||
| Battery charge time | 2.5 hours to full charge. | ||
| Battery charging system | Two-bay battery charger or in-imager charging. Optional 12 V automotive charging adapter. | ||
| AC operation | AC operation with included power supply (100 V AC to 240 V AC, 50/60 Hz). | ||
| Power saving | User selectable sleep and power off modes. | ||
| Colour Palettes | |||
| Standard palettes | 8: Ironbow, Blue-Red, High Contrast, Amber, Amber Inverted, Hot Metal, Grayscale, Grayscale Inverted. | ||
| Ultra Contrast™ palettes | 8: Ironbow Ultra, Blue-Red Ultra, High Contrast Ultra, Amber Ultra, Amber Inverted Ultra, Hot Metal Ultra, Grayscale Ultra, Grayscale Inverted Ultra. | ||
| General Specifications | |||
| Frame rate | 9 Hz versions. | ||
| Laser pointer | Yes. | ||
| LED light (torch) | Yes. | ||
| Color alarms (temperature alarms) | High temperature, low temperature, and isotherms (within range). | ||
| Center-point temperature measurement | Yes. | ||
| Spot temperature | Hot and cold spot markers. | ||
| User-definable spot markers | 3 user-definable spot markers. | ||
| Center box | Expandable-contractible measurement box with MIN-MAX-AVG temp display. | ||
| Infrared spectral band | 7.5 μm to 14 μm (long wave). | ||
| Operating temperature | -10 °C to +50 °C (14 °F to 122 °F). | ||
| Storage temperature | -20 °C to +50 °C (-4 °F to 122 °F) without batteries. | ||
| Relative humidity | 10% to 95% non-condensing. | ||
| Safety | IEC 61010-1: Overvoltage category II, Pollution Degree 2. | ||
| Electromagnetic compatibility | IEC 61326-1: Basic EM environment. CISPR 11: Group 1, Class A. | ||
| Australian RCM | IEC 61326-1. | ||
| US FCC | CFR 47, Part 15 Subpart B. | ||
| Vibration | 0.03 g2/Hz (3.8 g), 2.5 g IEC 68-2-6. | ||
| Shock | 25 g, IEC 68-2-29. | ||
| Drop | Engineered to withstand 2 meter (6.5 feet) drop with standard lens. | ||
| Size (H x W x L) | 27.7 x 12.2 x 16.7 cm (10.9 x 4.8 x 6.5 in). | ||
| Weight (battery included) | 1.04 kg (2.3 lb). | ||
| Enclosure rating | IEC 60529: IP54 (protected against dust, limited ingress; protection against water spray from all directions). | ||
| Fluke Ti480 warranty | Two-years (standard), extended warranties are available. | ||
| Recommended calibration cycle | Two-years (assumes normal operation and normal aging). | ||
| Supported languages | Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish. | ||
