GeoSLAM ZEB REVO RT Handheld 3D Scanner For Sale with a Best Price is a portable, lightweight laser scanner that makes it possible for you to quickly create precise 3D models while you’re out and about.
Achieve survey-grade relative accuracy of up to 6mm and capture 43,000 points per second—perfect for fine-tuning scanning and capturing minute details.
Before you leave your survey location, view point cloud data in real-time to see the regions you’ve covered (or missed) and the route you took.
The ZEB Revo may be used indoors, outdoors, and in locations with weak GPS reception thanks to its 30-meter range.
It boasts a robust IP54 rating and a rotating LiDAR sensor for the largest field of vision.
A variety of third-party software programs, in addition to GeoSLAM Connect & Draw, can be used to process data obtained from the ZEB Revo RT.
Heliguy provides the ZEB Revo RT with a complete ecosystem of support, including free consulting,
ZEB Revo RT Applications
Professional uses using handheld 3D scanning
Many different sectors can use the ZEB Revo RT, which is perfect for gathering data for precise 3D models.
It is a very portable instrument that works well for mapping locations that are indoors or underground as well as smaller spaces.
It is applicable to Buildings BIM Level Diagrams Facilities oversight
For industrial uses such as mine inspection and quality control, a LiDAR 3D scanner can enhance safety, cut down on time and expenses, and simplify the scanning of things such as buildings or landmarks.
SPECIFICATION
Maximum range: Up to 30m in optimal conditions; Typical max range 15-20m
Points per scan line: 432 (0.625 interval)
Field of view 270o x 360
Scan rate: 100 lines/s; 43200 points/s
Scan range noise: ±30mm
Laser safety classification: CLASS I Laser Product; (21 CFR 1040.10 and 1040.11)
Laser wavelength: 905nm
Operating conditions: Temperature 0o C to 35o C; Humidity – non condensing
Power supply: 14.8VDC, approx. 5.0A
Weight: Scanning head 1.0kg; Carry case and contents 4.1kg
Dimensions: Scanning head 80x113x140mm (287mm incl handle); Carry case and contents 470x220x180mm
Battery life: Approximately 90 minutes continuous use
