Leica RTC360 3D laser manual scanner kit For Sale with a Best Price

Leica RTC360 3D laser manual scanner kit For Sale with a Best Price gives customers the ability to record and capture their surroundings in three dimensions, increasing productivity and efficiency both in the field and in the office using quick, easy-to-use, accurate, and portable hardware and software. Professionals may discover the potential of any site and manage project complexity with accurate and dependable 3D representations thanks to the RTC360 3D laser scanner.
The RTC360 solution effectively combines the high-performance 3D laser scanner RTC360, the Leica Cyclone FIELD 360 mobile device app for edge computing that automatically registers scans in real time, and the Leica Cyclone REGISTER 360 office software that integrates your 3D model seamlessly into your workflow. The RTC360 solution is highly portable, highly automated, intuitive, and designed for maximum productivity.
In less than two minutes, capture scans and enhance High-Dynamic Range (HDR) imagery.
Pre-register your scans in the field without needing to manually record your movements from station to station. Add information tags to your data collection to enhance situational awareness among your teams, represent site reality, and highlight opportunities for improved planning.

Features:

• Fast
  With a measuring rate of up to 2 million points per second and advanced HDR imaging system, the creation of colored 3D point clouds can be completed in under two minutes. Plus, automated targetless field registration (based on VIS technology) and the seamless, automated transfer of data from site to office reduce time spent in the field and further maximize productivity.
• Agile
  Small and lightweight, the Leica RTC360 scanner’s portable design and collapsible tripod mean it’s compact enough to fit into most backpacks, ready to be taken anywhere. Once on-site, easy-to-use, one-button operation makes for fast, hassle-free scanning.
• Precise
  Low noise data allows for better images, resulting in crisp, high-quality scans that are rich in detail and ready for use in a range of applications. Combined with Cyclone FIELD 360 software for automated registration in the field, the Leica RTC360 scanner offers outstanding precision that can be checked on-site.
• Pre-registration in the field
  As part of the RTC360 solution, the Cyclone FIELD 360 app links the 3D data acquisition in the field with the laser scanner and data registration in the office with Cyclone REGISTER 360. On-site the user can automatically capture, register and examine scan and image data. The user interface combines easy handling of complex calculations with a graphical user guidance that offers a remarkable user experience, also for novice users.
• Cyclone FIELD 360
  The high-performance Leica Cyclone FIELD 360 mobile-device app is the perfect field companion for the Leica RTC360 3D laser scanner.

  With its intuitive user interface, remote scanner control and on-site point cloud display, navigation is a breeze – even for novice users – with full imagery and point cloud data delivered directly to the tablet using edge computing technology.

• Cyclone REGISTER 360
  The RTC360 companion release of Leica Cyclone REGISTER 360 allows for seamless import of pre-registered RTC360 field data. Data import is as easy as drag, drop, done. As no further manual alignment process is needed, excellent results are provided in a fraction of time.

  RTC360 data captured in the field is also immediately available in multiple software applications, serving field tags, assets, HDR imagery and 3D point cloud in JetStream powered solutions. In conjunction with the release of the RTC360 solution, a full release of the Cyclone product family is scheduled together with hardware shipments.

Specifications:

• 3D Laser Scanner : High-speed 3D laser scanner with integrated HDR spherical imaging system and Visual Inertial System (VIS) for real time registration
• Data acquisition : < 2 min for complete full dome scan and spherical HDR image at 6mm @ 10m resolution
• Real time registration : Automatic point cloud alignment based on real time tracking of scanner movement between setups based on Visual Inertial System (VIS) by video-enhanced inertial measurement unit
• Double scan : Automatic removal of moving objects
• Distance measurement : High-speed, high dynamic time of flight enhanced by Waveform Digitizing (WFD) technology
• Laser Class : 1 (in accordance with IEC 60825-1:2014), 1550nm (invisible)
• Field of view : 360° (horizontal) / 300° (vertical)
• Range : Min. 0.5 – up to 130 m
• Speed : Up to 2‘000‘000 pts / sec
• Resolution : 3 user selectable settings (3/6/12mm @ 10m)
• Accuracy : Angular accuracy 18”
  Range accuracy 1.0 mm + 10 ppm
  3D point accuracy
  1.9 mm @ 10 m
  2.9 mm @ 20 m
  5.3 mm @ 40 m
• Range noise : 0.4 mm @ 10 m, 0.5 mm @ 20 m
• Camera : 36 MP 3-camera system captures
  432 MPx raw data for calibrated
  360° x 300° spherical image
• Speed : 1 minute for full spherical HDR image at any light condition
• HDR : Automatic, 5 brackets
• Visual Inertial System : Video enhanced inertial measuring system to track movement of the scanner position relative to the previous setup in real time
• Tilt : IMU based, Accuracy: 3‘ for any tilt
• Additional sensors : Altimeter, Compass, GNSS
• On scanner : Touch-screen control with finger touch, full color WVGA graphic display 480 x 800 pixels
• Mobile devices : Leica Cyclone FIELD 360 app for iPad or Android tablets including:
  – Remote control of scan functions
  – 2D & 3D data viewing
  – Tagging
  – Automatic alignment of scans
• Wireless : Integrated wireless LAN (802.11 b/g/n)
• Data storage : Leica MS256, 256GB exchangeable USB 3.0 flash drive
• Housing : Aluminium frame and sidecovers
• Dimensions : 120mm x 240mm x 230mm / 4.7‘‘ x 9.4‘‘ x 9.1Weight : 5.35 kg / 11.7 lbs, nominal (w/o batteries)
  Mounting mechanism : Quick mounting on 5/8“ stub on lightweight tripod / optional tribrach adapter / survey tribrach adapter available
• Internal battery : 2 x Leica GEB361 internal, rechargeable Li-Ion batteries.
  Duration: Typically up to 4 hours
  Weight: 340 g per battery
• External : Leica GEV282 AC adapter
  Operating temperature : 5° to +40° C
  Storage temperature : 40° to +70° C
  Operating low temperatures : 10° to +40°C
  Dust/Humidity : Solid particle/liquid ingress protection IP54
