Olympus OmniScan SX Flaw Detector For Sale with a Best Price
Original price was: $7.100.$5.800Current price is: $5.800.
In stock
Get an Enquiry Buy it now
Olympus OmniScan SX Flaw Detector For Sale with a Best Price is proud to introduce the OmniScan® SX, a flaw detector that benefits from more than 20 years of phased array experience and shares the OmniScan DNA. For improved ease of use, the OmniScan SX features a new streamlined software interface displayed on an 8.4 in. (21.3 cm) touch screen. A single-group and non-modular instrument, the OmniScan SX is easy to operate and cost-effective for less demanding applications.
The OmniScan SX comes in two models: the SX PA and SX UT. The SX PA is a 16:64PR phased array unit, which, like the UT-only SX UT, is equipped with a conventional UT channel for pulse-echo, pitch-catch or TOFD inspection. Compared to the OmniScan MX2, the SX is 33% lighter and 50% smaller, offering an unprecedented level of portability for an OmniScan.
The OmniScan SX touch screen offers a full-screen mode option that maximizes visibility, essentially converting many menu functions into easy touch-screen operations. The intuitive interface provides smooth menu selection, zooming, gate adjustments, cursor movements, and text and value input. These, along with other premium integrated features, including easy-to-follow setup and calibration Wizards, a rapid refresh rate for both the S-scan and A-scan displays, and a fast pulse repetition frequency (PRF), make the OmniScan SX a highly efficient inspection tool.
360 degree view of portable OmniScan SX
The OmniScan SX is fully compatible with the extensive portfolio of Olympus scanners, probes and accessories, as well as with its dedicated software companions, NDT SetupBuilder and OmniPC. Combined, the complete family of software and hardware contributes to a streamlined and efficient inspection workflow, from design and setup to acquisition and analysis.
Olympus OmniScan SX Flaw Detector New features include:
Export C-Scan
New End-View with group merge
Interleave
Analysis attenuation gain
Scrolling layouts for easy interpretation
Improved accessibility with more interactive menus
Optimised main menus and wizards
Onboard compound scan
Curved geometry ray-tracing for longitudinal welds
Specification Olympus OmniScan SX Flaw Detector :
| Housing | Overall dimensions (W x H x D) | 267 mm × 208 mm × 94 mm (10.5 in. × 8.2 in. × 3.7 in.) |
|---|---|---|
| Weight | 3.4 kg (7.5 lb) with battery | |
| Data Storage | Storage devices | SDHC card* or most standard USB storage devices. *Lexar® brand memory cards are recommended for optimized results. |
| Data file size | 300 MB | |
| I/O Ports | USB ports | 2 USB ports, compliant with USB 2.0 specifications |
| Audio alarm | Yes | |
| Video output | Video out (SVGA) | |
| I/O Lines | Encoder | 2-axis encoder line (quadrature, up, down, or clock/direction) |
| Digital input | 4 digital TTL inputs, 5 V | |
| Digital output | 3 digital outputs TTL, 5 V, 15 mA maximum per output | |
| Acquisition on/off switch | Yes, through configuration of a digital input | |
| Power output line | 5 V, 500 mA power output line (short-circuit protected) | |
| Pace input | 5 V TTL pace input | |
| Display | Display size | 21.3 cm (8.4 in.) (diagonal) |
| Resolution | 800 pixels x 600 pixels | |
| Brightness | 600 cd/m2 | |
| Viewing angles | Horizontal: –80° to 80° Vertical: –60° to 80° | |
| Number of colors | 16 million | |
| Type | TFT LCD | |
| Power Supply | Battery type | Smart Li-ion battery |
| Number of batteries | 1 | |
| Battery life | Minimum 6 hours under normal operating conditions | |
| Environmental Specifications | Operating temperature range | -10 °C to 45 °C (14 ºF to 113 ºF) |
| Storage temperature range | –20 °C to 60 °C (–4 ºF to 140 ºF) with battery –20 °C to 70 °C (–4 ºF to 158 ºF) without battery |
|
| Relative humidity | Max. 70% RH at 45°C noncondensing | |
| Ingress protection rating | Designed to meet requirements of IP66 | |
| Shockproof rating | Drop-tested according to MIL-STD-810G 516.6 | |
| Ultrasound Specifications (applies to OMNISX-1664PR) | Connectors | 1 Phased Array connector: Olympus PA connector 2 UT connectors: LEMO 00 |
| Number of focal laws | 256 | |
| Probe recognition | Automatic probe recognition |
| Pulser/Receiver | Aperture | 16 elements | ||
|---|---|---|---|---|
| Number of elements | 64 elements | |||
| Pulser | PA Channels | UT Channel | ||
| Voltage | 40 V, 80 V, and 115 V | 95 V, 175 V, and 340 V | ||
| Pulse width | Adjustable from 30 ns to 500 ns; resolution of 2.5 ns | Adjustable from 30 ns to 1,000 ns; resolution of 2.5 ns | ||
| Pulse shape | Negative square wave | Negative square wave | ||
| Output impedance | 35 Ω (pulse-echo mode); 30 Ω (pitch- catch mode) |
<30 Ω | ||
| Receiver | PA Channels | UT Channel | ||
| Gain | 0 dB to 80 dB, maximum input signal 550 mVp-p (full-screen height) | 0 dB to 120 dB maximum input signal 34.5 Vp-p (full-screen height) | ||
| Input impedance | 60 Ω (pulse-echo mode); 150 Ω (pitch- catch mode) |
60 Ω (pulse-echo mode); 50 Ω (pulse-receive mode) |
||
| System bandwidth | 0.5 MHz to 18 MHz (NOTE: The previously stated 0.6 MHz lower limit used a strict −3 dB attenuation for the cutoff frequency.) | 0.25 MHz to 28 MHz (–3 dB) | ||
| Beamforming | Scan type | Sectorial or linear | ||
|---|---|---|---|---|
| Group quantity | 1 | |||
| Data Acquisition | PA Channels | UT Channel | ||
| Effective digitizing frequency | Up to 100 MHz | 100 MHz | ||
| Maximum pulsing rate | Up to 6 kHz (C-scan) | |||
| Data Processing | PA Channels | UT Channel | ||
| Number of data points | Up to 8,192 | |||
| Real-time averaging | PA: 2, 4, 8, 16 | UT: 2, 4, 8, 16, 32, 64 | ||
| Rectifier | RF, full wave, half wave +, half wave – | |||
| Filtering | 3 low-pass, 3 band-pass, and 5 high-pass filters | 3 low-pass, 6 band-pass, and 3 high-pass filters (8 low-pass filters when configured in TOFD) | ||
| Video filtering | Smoothing (adjusted to probe frequency range) | |||
| Data Visualization | A-scan refresh rate | A-scan: 60 Hz; S-scan: 60 Hz |
|---|---|---|
| Data Synchronization | On internal clock | 1 Hz to 6 kHz |
| On encoder | On 2 axes: from 1 to 65,536 steps | |
| Programmable Time-Corrected Gain (TCG) | Number of points | 16: One TCG (time-corrected gain) curve per focal law |
| Maximum slope | 40 dB/10 ns | |
| Alarms | Number of alarms | 3 |
| Conditions | Any logical combination of gates |
