Pruftechnik Optalign Touch Laser Shaft Alignment System For Sale with a Best Price

Pruftechnik Optalign Touch Laser Shaft Alignment System For Sale with a Best Price was created by some of the top alignment specialists in the world to provide the simplest solutions to issues. Machine shaft alignment is made possible by its powerful, quick, and effective sensALIGN 5 laser and sensor heads.

OPTALIGN Touch integrates hardware, software, and WiFi connectivity for common chores and conventional machines. It uses the cloud to deliver exact alignment data. Almost anyone can operate its easily navigable user interface; all they need to do is follow the three simple stages for every laser shaft alignment procedure: dimensions, measure, and result.

All of the well-known PRUFTECHNIK functions that are required for daily alignment tasks are available with the OPTALIGN Touch, including thermal growth correction, soft foot recognition, dynamic tolerance (TolChek), simultaneous Live Move, InfiniRange, and SWEEP mode measurement.

Key benefits Optalign Touch :
Work faster without sacrificing accuracy
With intuitive setup and data acquisition and an easy-to-use handheld device, even complex alignment jobs can be done quickly with no loss in accuracy and precision.
Leverage advanced laser shaft alignment capabilities
The powerful hardware and software features in the OPTALIGN touch simplify the way you perform mounting, measuring, and shimming.
With mistake-correcting capabilities, this tool adapts to both the alignment challenge and experience level of the user.
Transfer data to and from the cloud
Send and receive alignment data from and to the ARC 4.0 PC software via an integrated WiFi connection. Monitor and trend your data for analysis and action.

sensALIGN technology Optalign Touch
Based on the innate PRUFTECHNIK single laser technology, the sensALIGN Series technology offers extremely accurate measurement outcomes as well as simple field setup and measurement. Two HD big position-sensitive detectors (PSD) and MEMS inclinometers are part of the sensALIGN 5 sensor set. No matter how much of a misalignment there is, the initial alignment condition may always be measured and recorded when combined with the detector extension capacity (InfiniRange). Additionally, this technique enables the monitoring of machine adjustments in both vertical and horizontal directions at the same time, beginning at any angle where the sensor stops.

Adaptive Alignment for any maintenance workshop
Single-laser technology sensALIGN 5 featuring continuous SWEEP mode, Live Move, and InfiniRange
Active Situational Intelligence speeds every alignment task
WiFi and Bluetooth communication
Continuous SWEEP measurement mode: Automatic collection of alignment data during shaft rotation
Live Move: simultaneous real-time machine corrections in both horizontal and vertical directions
Automatic evaluation of the alignment condition (Dynamic Tolerance)
Soft foot check – measure, correct, and save results
InfiniRange extends detector measurement range to handle gross misalignment and large coupling separation distances
Fully featured with all shaft alignment relevant functions
Upgrade with sensALIGN 7 laser/sensor heads: the whole world of PRUFTECHNIK’s adaptive alignment features becomes available

Specifications:
Computer Intel XScale Processor, 64 MB RAM, 64 MB Internal Flash, 64 MB Compact Flash Memory, power saving management
Display Transflective (sunlight-readable) backlit color graphic display (1/2 VGA, 480 x 320 pixel, 118 mm x 80 mm), contrast and illumination (0 … 70 cd/m squared) adjustable
Power Supply Li-Ion rechargeable battery (7.2 V/6,0 Ah),
Operating time: Approximately 25 hours
Disposable batteries: (6 x 1,5 V [IEC LR14]),
Operating time: Approximately 12 hours
Mains power: (110 V/220 V AC)
Interfaces USB Host/Slave (for printer, keyboard or PC communication),
I-Data-socket (for receiver), RS232 (Serial for receiver),
Bluetooth communication
Laser GaAIAs semiconductor laser, Beam divergence < 0.3 mrad, Beam power < 1 mW, Laser safety class 2 (FDA 21CFR 1000 und 1040),
Power supply 9V block battery (IEC 6LR61, alkali or lithium)
Receiver 5-axis receiver: 2 planes (4 displacement axes), 1 inclination 360 degrees,
protection from ambient light, unlimited dynamically extendible measurement area, resolution 1 um (0.04 mil) and angular 10 urad,
error < 2%, error rotation angle < 2 degrees, measurement range approx 20 Hz
Environmental protection Computer: IP 65
Laser: IP 67
Receiver: IP 67
Temperature range (storage) Computer: -20 to 60 C
Laser: -20 to 60 C
Receiver: -20 to 80 C
Temperature range (operation) Computer: 0 to 45 C
Laser: 0 to 60 C
Receiver: 0 to 60 C
Dimensions Computer: 243 x 172 x 61 mm
Laser: 105 x 67 x 47 mm
Receiver: 105 x 67 x 47 mm
Weight Computer: 1 kg (without battery)
Laser: 165 g
Receiver: 190 g
Maximum measurement distance Laser: 10 m
CE conformity EN 61326 (general), EN 55022 (emission), EN 61000-4-2, -3, -4, -5, -6, -11 (interference)
Included:

Pruftechnik Rotalign Ultra Laser Shaft Alignment System w/ (BC# 40968)
Licensed Applications:
Program Manager V1.84
Shaft Alignment V1.26
Rotalign Laser
Rotalign Receiver
Rotalign Ultra USB Cable
Rotalign Ultra USB / Peripheral Cable
Tape Measure
(2) Brackets w/ Chains
(3) Chains
(20) Support Posts w/ Case
AC Adapter/Charger
Hard Carrying Case
