Skyray Genius 5000 Handheld X-ray Scanner Fluorescence Spectrometer Machine For Sale with a Best Price The Genius Handheld XRF Spectrometer is designed to quickly and accurately detect any element, ranging from magnesium to uranium, through non-destructive elemental identification and composition analysis using an SDD detector. The portability and compact size of a handheld XRF paired with performance and accuracy comparable to a desktop XRF system. Genius XRF offers a variety of software options and can be used for a wide range of applications.
Features
Quick measurement with findings in five seconds, along with rapid nondestructive detection
The accuracy of the SDD Detector is comparable to that of most desktop XRF systems.
During testing, the integrated GPS logs latitude, longitude, and altitude.
Without a sample, the auto X-ray tube shuts off.
Mini-USB, Bluetooth, and an expandable SD card for PC connectivity and data storage
On request, customers can add and change customized workcurves.
Helium gas detection of light elements
High resolution camera integrated for in-the-moment sample observation .
echnical Specifications :
1.Model:The 4 th generation EDX analyzer-Genius XRF series.
2.Analysis method:Energy dispersive X-ray fluorescence analysis method.
3.Measuring range of elements: Mg to U.
4.Simultaneously detect elements:Simultaneously detect tens of elements.
5.Processor and RAM:CUP: 667MHz, RAM:256M , Maximum expanded storage: 32G, Standard configuration: 2G , can store large amounts of data.
6.Content range: ppm～99.99%.
7.Testing time :3-30 seconds.
8.GPS、WIFI:Built-in system.
9.Battery time: Lithium battery,which can be charged, with maximum capacity of 7800mAH, can continuously work for 8 hours; Equiped with wide voltage(110V-220V) general adapter, can work under alternating current.
10.Testing object:Solid, liquid , powder.
11.Detector:25mm2 0.3mil，SDD detector.
12.Detector resolution: Lowest resolution can be 139eV .
13.Excitation source:40KV/100uA-Ag anode window miniature X light tube and high voltage source.
14.Collimator and filter:Collimator of 4.0 or 2.0 diameter, automatic switch of 6 types filter groups. 12 kinds of groups, world’s most compound mode, can satisfy various kinds of samples testing.
15.Video system:HD camera.
16.Screen :TFT-LCD touch screen, resolution 640*480.
17.Detection limit:Lowest detection limit accounts to ppm level.
18.Testing window:12mm.
20.Safety :Self-contained password manager mode.
19.Gas charging system: Helium charging at ordinary pressure system.
20.Data transmission: Digital multi-channel technology, SPI data transmission, quick analysis, high counting rate, waterproof miniature USB,which can be connected to desktop computer．
21.Humidity :≤90%.
22.Temperature: -20℃～+50℃.
23.Size :234×306×82mm（L×H×W）.
24.Weight:1.9Kg（with battery），1.6Kg（without battery）.
