Stonex F6 Handheld 3D laser Scanner For Sale with a Best Price is specifically made for quickly and accurately scanning small, highly detailed objects that are close together.
F6 SR is the best option for quick scanning since it offers exceptional data quality and is based on a unique novel encoding method.
The F6 SR is operated by Echo, an advanced and easy-to-use integrated software with high-end features such as:
Advanced scanning modes with real time feedback
Powerful 3D data editing tools
Flexible integration to 3rd party software based on Mantis Vision DLL or SDK
Advanced meshing with full color projection
Composing registration of models from different scans
Multiple interfaces: tablet/laptop/VR
User interface: touch screen/ desktop
SYSTEM BENEFITS:
Portable & light weight
Not limited solely to small objects
Accurate and fast
IR light for operation in any lighting conditions
No scene preparation necessary
Geometry deciphered via encoding
Accessibility to hard-to-reach places
Hot shoe connection for:
Wireless synchronization of multiple F6 devices for dynamic motion capture
Flash light
User friendly – operable following a brief training
INDUSTRIES AND APPLICATIONS:
Automotive and marine
Architecture, Engineering, Construction
Forensics
Education & Research
Aviation
Designers
Art
VR game designers and special effects
Stonex F6 Handheld 3D laser Scanner Specification :
| Accuracy | up to 0.1mm |
| Depth resolution | up to 0.5mm |
| Noise level | less than 0.25mm |
| Eye safety | Class 1 |
| Lighting conditions | From complete darkness to daylight |
| Depth of field | 0.25-0.75 m |
| Field of view @ 0.25m | 245X345mm |
| Field of view @ 0.75m | 735X1030mm |
| Angular field of view | HxW 54° x 68° |
| Color camera resolution | 1.3 MPix |
| Video frame rate | 8 FPS |
| Data acquisition speed | up to 640,000 points/sec |
| Max points per frame | 80,000 |
| Dimensions | 32 x 12 x 4.5 cm |
| Weight | 1 Kg |
| Working temperature | 5˚C to 50˚C |
Stonex F6 Handheld 3D laser Scanner package includes:
1x F6 Instrument unit
1x F6 Carrying case
1x F6 Charger
1x F6 USB cable
1x ECHO software, user license
