API Omnitrac 2 Laser Tracker With vProbe Includes Brunson Tracker Stand For Sale with a Best Price

API Omnitrac 2 Laser Tracker With vProbe Includes Brunson Tracker Stand For Sale with a Best Price stable performance in a challenging setting. For many different indoor and outdoor applications, Omnitrac 2 is the perfect measuring tool. The product’s wireless design and compact structure allow it to fit into a small space that is inaccessible to other measurement devices.
Because of its sturdy structure and design, the Omnitrac 2 is perfect for use in demanding production environments. Additionally, it has an integrated battery that can run the device constantly for up to six hours. An extra AC/DC interface is also available.

After a few minutes of operation, Omnitrac 2 reached approximately 90% accuracy. Omnitrac 2 weighs 10 kg and has a measuring range of up to 100 meters at a working temperature of -10 to 60 degrees Celsius.
Completely integrated, with unmatched small size. In order to transfer data over WiFi, Omnitrac 2 incorporates all of the measurement-related equipment, such as the tilt sensor, weather station, controller, and battery.
ADM (absolute ranging) technology powers Omnitrac 2. Anywhere can be used for measuring with Omnitrac 2: on top, on a vertical wall, tilted, under, or inside components.
With the Omnitrac 2 laser tracker, you can measure anything, anywhere.

Features :

Completely wireless operation (Integrated controller, weather station, tilt sensor, battery, WiFi)
Battery operation (3-6 hours) with internal, rechargeable cells (non-removable by user)
High accuracy ADM able to do dynamic measurement
Autolock (Camera Assisted Automated Target Acquisition)
Onboard level sensor
Highly portable (only 10.8 Kg with a single transport case)
Mounting versatility: mount sideways, upside down, underneath, or directly on your part
Compatible with the current API quick-link instrument stands and accessories

SPECS :

Range of Measurements:

Linear Range (Diameter): 200 m (with selected targets), 160 m (525 ft with 80m target)
System Performance:

Azimuth Range: ± 320º (640º end to end)

Elevation Range: 79º / -59º

Angular Resolution: ± 0.018 arc seconds

System Angular Accuracy: 3.5 μm/m*

System Resolution: 0.02 arc seconds

Maximum Lateral Target Speed: 180º / sec

Maximum Acceleration: > 2 g

Maximum Battery Life: 6 hours (internal battery, Capable of hot-switching with External battery)

Internal Level Accuracy: ±2 arc-second

Internal Level Range: ±2 degrees

ADM2:

IR Laser (ADM-Maxx™): Class I (eye safe)

Accuracy: ± 25 μm or 1.5 μm/m* (which ever is greater)

Resolution: 0.1 μm

Environmental:

OperatingTemperature: -10º C to > 45º C

Storage Temperature: -10º C to 60º C

Barometric Pressure: 8 mmHg – 825 mmHg

Relative Humidity: 10-95% non-condensing

Altitude: -700 m – 3000 m

Autolock (Automated Target Search):

Full Range Pointing Accuracy: 2”

Field Of Vision: ±12.5º (diagonal)

Dimensions:

Tracker Weight: 10.9 kg (24 lb)

Tracker Size: Height: 43 cm (16.95 inches)

Width: 19.8 cm (7.8 inches)

Includes:

(1X) API OmniTrac 2 Laser Tracker with all standard accessories
(1X) API Control Software on USB
(1X) S-FIX Fixed Height Carbon Tripod
(1X) Laser Tracker Tooling Kit with some extras
(1X) API SMR
(1X) Hexagon Metrology 800 mm SMR
(1X) SMX Retro Probe 100 Kit
