Creaform HandySCAN BLACK series Elite 3D Scanner For Sale with a Best Price is a strong and adaptable metrology-grade 3D scanner that is perfect for applications involving product development and quality control. The quick and adaptable HandySCAN Black 3D scanner from Creaform is ideal for professionals in metrology, manufacturing, and design who need to take precise measurements of actual things in three dimensions anywhere.
Creaform HandySCAN BLACK series Elite 3D Scanner In terms of portable metrology-grade 3D scanners, line-up is the standard. The lightweight, portable HandySCAN Black 3D scanner, now in its third generation, produces incredibly accurate and reproducible results even in challenging situations and on complicated materials. It is simple to operate.
Accurate, High-Resolution 3D Measurements
HandySCAN Black produces data that are accurate, high-resolution, and repeatable regardless of the user’s experience or the quality of the measuring setup. Thanks to dynamic reference, an accurate and high-quality scan may be obtained even when the part and scanner move throughout the measurement process.
There is no need for an external tracking device or tripod to function with this portable 3D scanner as it is a standalone device. It may be carried anywhere and utilized in any kind of situation without compromising its functionality because it can fit into a tiny luggage.
High-Performance Tools to Meet Rising Quality Standards
- 4X resolution: Captures fine details and large volumes thanks to the unique and versatile combination of improved high-performance optics and multiple blue laser technology.
- 3X faster measurement speed and instant mesh: Larger scanning area featuring 11 blue laser crosses that take up to 1,300,000 measurements per second, ultimately cutting down the time between acquisition and workable files.
- More accurate and traceable measurements: Volumetric accuracy of 0.020 mm + 0.040 mm/m (0.0008 in. + 0.0005 in./ft) based on VDI/VDE 2634 part 3 as well as ISO 17025, ensuring reliability and full traceability to international standards.
- Available in BLACK and BLACK|Elite: Customers can choose from two models based on their needs: part complexity, measurement speed, accuracy, etc.
Technical Specifications:
| HandySCAN 307 | HandySCAN BLACK | HandySCAN BLACK Elite | |
| Accuracy | Up to 0.040 mm (0.0016 in) | 0.035 mm (0.0014 in) | 0.025 mm (0.0009 in) |
| Volumetric accuracy(2) (based on part size) | 0.020 mm + 0.100 mm/m (0.0008 in + 0.0012 in/ft) | 0.020 mm + 0.060 mm/m (0.0008 in + 0.0007 in/ft) | 0.020 mm + 0.040 mm/m (0.0008 in + 0.0005 in/ft) |
| Volumetric accuracy with MaxSHOT Next™ | Elite(3) | 0.020 mm + 0.015 mm/m (0.0008 in + 0.00018 in/ft) | ||
| Measurement resolution | 0.100 mm (0.0039 in) | 0.025 mm (0.0009 in) | |
| Mesh resolution | 0.200 mm (0.0078 in) | 0.100 mm (0.0039 in) | |
| Measurement rate | 480,000 measurements/s | 800,000 measurements/s | 1,300,000 measurements/s |
| Light source | 7 red laser crosses | 7 blue laser crosses | 11 blue laser crosses (+ 1 extra line) |
| Laser class | 2M (eye-safe) | ||
| Scanning area | 275 x 250 mm (10.8 x 9.8 in) | 310 x 350 mm (12.2 x 13.8 in) | |
| Stand-off distance | 300 mm (11.8 in) | ||
| Depth of field | 250 mm (9.8 in) | ||
| Part size range (recommended) | 0.1–4 m (0.3–13 ft) | 0.05–4 m (0.15–13 ft) | |
| Software | VXelements | ||
| Output formats | .dae, .fbx, .ma, .obj, .ply, .stl, .txt, .wrl, .x3d, .x3dz, .zpr, .3mf | ||
| Compatible software * | – 3D Systems (Geomagic® Solutions) – InnovMetric Software (PolyWorks) – Dassault (CATIA V5 and SOLIDWORKS) – PTC (Creo) – Siemens (NX and Solid Edge) – Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage) | ||
| Weight | 0.85 kg (1.9 lb) | 0.94 kg (2.1 lb) | |
| Dimensions (LxWxH) | 122 x 77 x 294 mm (4.8 x 3.0 x 11.6 in) | ||
| Connection standard | 1 X USB 3.0 | ||
| Operating temperature range | 5-40 °C (41-104 °F) | ||
| Operating humidity range (non-condensing) | 10-90% | ||
| Certifications | EC Compliance (Electromagnetic Compatibility Directive, Low Voltage Directive), compatible with rechargeable batteries (when applicable), IP50, WEEE | ||
| Patents | CA 2,600,926, CN 200680014069.3, US 7,912,673, CA 2,656,163, EP (FR, UK, DE) 1,877,726, AU 2006222458, US 8,032,327, JP 4,871,352, US 8,140,295, EP (FR, UK, DE) 2,278,271, EP (FR, UK, DE) 2,230,482, IN 266,573, US 7,487,063, CA 2,529,044, EP (FR, UK, DE) 3,102,908, US 15/114,563, CN 201580007340X | ||
