GSSI StructureScan Pro GPR For Sale With Best Price is an adaptable concrete inspection system that provides a large range of antenna choices for use with concrete and other materials. The StructureScan Pro, which is based on the SIR 4000 controller, offers GPR experts solutions for any scanning scenario.
This controller connects the legacy of our traditional analog antennas with our next generation of digital offerings. The SIR-4000 is the first high-performance GPR data acquisition system designed to operate with analog and digital antennas. It is a ground penetrating radar control unit with an integrated rugged display.When combined, these enable true flexibility and variety by catering to a broad spectrum of users, from novices to experts, across several applications. For effective data collection and visualization, it has special collection modules such as Quick 3D, UtilityScan, StructureScan, and Expert Mode. Additionally, it has sophisticated filtering and displaying techniques for “in-the-field” processing and imaging.The 10.4-inch high-definition LED display, straightforward user interface, plug-and-play GPS integration, and Wi-Fi-enabled data transfer features are all included in the fully integrated SIR 4000. The SIR 4000 is engineered with several unique features, such as an impact-resistant design and a casted aluminum chassis that provide temperature stability, resulting in a full IP 65 rating that can survive demanding jobsite conditions.
GSSI StructureScan Pro sale includes:
GSSI SIR 4000 control unit
1600 MHz or 2600 MHz antenna
Model 615 handcart with encoder
7 meter control cable
Rugged carrying case
2x batteries and charger
2 year GSSI warranty
GSSI StructureScan Pro GPR Technical Specifications
| System | SIR 4000 |
| Antennas | Compatible with all GSSI antennas |
| Number of Channels | Records data from 1 single-frequency antenna or 1 dual-frequency antenna |
| Data Storage | 32 GB Flash, 1 GB RAM |
| Display | 10.4” LED |
| GPS | Data logged internally |
| Display Modes | Linescan, Full 3D |
| Environmental Rating | IP64 |
| Data Format | RADAN (dzt) |
| Output Data Format | 32-bit |
| Scan Interval | User-selectable, up to 4000 scans/sec |
| Number of Samples per Scan | 256, 512, 1024, 2048, 4096, 8192, 16384 |
| Operating Modes | Continuous (time) or survey wheel (distance triggered) or point mode |
| Time Range | 0-20,000 nanoseconds full scale, user-selectable Gain: manual adjustment from -42 to +126 dB Number of segments in gain curve is user-selectable from 1 to 8 |
| Standard Real-Time Filters | Infinite Impulse Response (IIR) – Low and High Pass, vertical and horizontal – Finite Impulse Response (FIR) – Low and High Pass, vertical and horizontal |
| Advanced Real-Time Filters | Migration, Surface Position Tracking, Signal Noise Floor Tracking, Adaptive Background Removal |
| Automatic System Setups | Storage of an unlimited number of system setup files for different survey conditions and/or antenna deployment configurations |
| Automatic Antenna Recognition | Automatic recognition of Smart Antennas to allow maximum compliant transmit rate |
| Languages | English, Chinese, Japanese and French |
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) |
| Battery | Inspired Energy Ni2040ED, 3 hour runtime (battery life dependent on level of display brightness) |
| Transmit Rate | Up to 800 KHz (International) US/Canada and CE rates depend on antenna model |
| Input/Output | |
| Available Ports | Analog and Digital, RS232, HDMI, Ethernet to PC, USB 2.0 port and mini USB |
| Ethernet | RJ45 100BT Ethernet |
| USB Host | USB host with external keyboard support, USB flash drive support and USB HUB support |
| Dimensions | 14x10x2.75 in (36x25x7 cm) |
| Weight | 10 lbs (4.53 kg) including battery |
| Relative Humidity | <95% non-condensing |
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) |
