Leica ScanStation P16 3D Laser Scanner total station For Sale with a Best Price is the ideal starting point for exploring the world of 3D laser scanning. Its appealing price-performance ratio and easy-to-use interface make it a desirable option for all short-range applications up to 40 meters, even for users who are not surveying.
The new Leica ScanStation series is available from Leica Geosystems as an integrated component of a full scanning solution that also includes service, support, software, hardware, and training. The industry’s top 3D point cloud software suite, Leica CloudWorx plug-in tools for CAD systems, Leica Cyclone stand-alone software, and the free Leica TruView, can analyze data from 3D laser scanners. Low cost of ownership and maximum productivity are guaranteed by a global service and support network in conjunction with specially designed training.
Every detail counts, so the new ScanStation laser scanners from Leica Geosystems are the best option if you need to capture 3D geometry of roads, rails, tunnels, and bridges or high-definition scan data for topographic maps and as-built surveys. You know you’ll need an accurate long range scanning tool for your civil engineering and infrastructure projects.
You know you’ll need precise life cycle representations in plant engineering and ship building, whether you need an as-built depiction of a vast industry complex, a thorough scan of a pipe system, or a 3D point cloud of a ship hull. Because every detail counts, Leica Geosystems’ new ScanStation laser scanners are the ideal option due to their speed, range, accuracy, and robustness.
Real-time planning of design and building projects with prompt and precise deliverables is crucial, regardless of whether you require a 2D floor plan, a 3D model for incorporation into Building Information Modelling (BIM), or a comprehensive as-built representation of a façade. Because every detail counts, Leica Geosystems’ new ScanStation laser scanners are the best option.
Leica ScanStation P16 3D Laser Scanner total station Specifications:
| System Accuracy | |
| Accuracy of single measurement | Range accuracy: 1.2mm + 10ppm over full range Angular accuracy: 8″ horizontal; 8″ vertical 3D position accuracy: 3mm at 40m |
| Target acquisition | Up to 40m in post-processing software |
| Dual-axis compensator | Liquid sensor with real-time onboard compensation, selectable on/off, resolution 1″, dynamic range ±5′, accuracy 1.5″ |
| Distance Measurement System | |
| Type | Ultra-high speed time-of-flight enhanced by Waveform Digitizing (WFD) technology |
| Wavelength | 1550nm (invisible) / 658nm (visible) |
| Laser class | 1 (in accordance with IEC 60825:2014) |
| Beam divergence | <0.23mrad (FWHM, full angle) |
| Beam diameter at front window | ≤ 3.5mm (FWHM) |
| Range and reflectivity | Up to 40m; 18% reflectivity (minimum range 0.4m) |
| Scan rate | Up to 1’000’000 points per second |
| Range noise | 0.4mm rms at 10m 0.5mm rms at 40m |
| Field-of-View | Horizontal: 360° Vertical: 270° |
| Data storage capacity | 256GB internal solid-state drive (SSD) or external USB device |
| Communications/ Data transfer | Gigabit Ethernet, integrated Wireless LAN or USB 2.0 device |
| Onboard display | Touchscreen control with stylus, full color VGA graphic display (640×480 pixels) |
| Laser plummet | Laser class 1 (IEC 60825:2014) Centering accuracy: 1.5mm at 1.5m Laser dot diameter: 2.5mm at 1.5m Selectable ON/OFF |
| Imaging System | |
| Internal camera | Resolution: Pixel size: Video: White balancing: HDR: |
| External camera | Canon EOS 60D and 70D supported |
