Topcon GLS-2200 Laser Scanners 3D For Sale with a Best Price is incredibly feature-rich, being the first to have dual internal digital cameras (telephoto and wide-angle) for better color image capturing.
With unparalleled speed, the GLS-2000 offers a 1,150′ (350m) scanning range that is “eye-safe.” The GLS-2000 is a perfect tool for a variety of applications since it can be used fast and conveniently without sacrificing precision thanks to its one-touch scanning feature. The accuracy and efficiency offered by the GLS-2000 will be especially helpful for “Scan-to-BIM” and “As-Built” projects.
With the newest workflow and scanning technologies, you can do any task quickly. With the help of the GLS-2200’s distinctive survey-style setup and intuitive processing software, laborious scanning procedures may be quickly and easily completed.
Package Includes:
– Topcon GLS-2200
– Battery (BDC72) 4 pieces
– Battery Charger (CDC77) 2 pieces
– Charging Cable (EDC113) 2 pieces
– Carrying case
– Silica gel
– Cloth wipe
– SD card
– SD card case
– Tool kit
– Target sheet
– Centering target
– Instruction manual
– Warranty card
Specification:
System Performance | |
Maximum range at specified reflectivity | |
Standard Mode | 350m at 90% |
High Speed Mode | 210m at 90% |
Low Power Mode | 210m at 90% |
Single Point Accuracy | |
Distance | 3.5mm (1-150m), 1sigma |
Angle | 6” |
Dual Axis Compensator | |
Resolution | 1” |
Accuracy | 4” |
Range | -/+ 6’ |
Target Deftection Accuracy | 3” at 50m |
Laser Scanning System | |
Type | Pulsed Precise Scan Technology |
Laser Class | 3R (High Speed / Standard) 1M (Low Power) |
Scan Density (Resolution) | |
Spot Size | <11.2mm(1-150m, FWHM) |
Maximum Sample Density | 3mm at 10m |
Field of view (per scan) | Horizontal: 360º Vertical: 270º |
Color Digital Imaging | 5M pixel, Dual (170°/8.9°) |
Scanning Control | |
Control System | On-board |
Display | VGA Color Touch Display |
Keyboard | 3 Key |
Data Storage | SD Card |
Environmental | |
Operation Temperture | -5ºC to 45ºC |
Storage Temperture | -20ºC to 60ºC |
Dust/Humidity | IP54 |
Physical | |
Dimensions | 152 x 293 x 412mm |
Weight | 11kg |
Keyboard | 21 keys |
