GE XL Detect plus VideoProbe For Sale with a Best Price

GE XL Detect plus VideoProbe For Sale with a Best Price provides excellent remote visual examination outcomes at a cost-effective pricing. A durable, lightweight, portable video borescope that has all the functionality you require, including the ability to store still and video images within or externally on a detachable USB drive.

Benefits of the XL Detect+:

• Have faith in the outcomes.
  Perform quick, accurate inspections with excellent image quality and take advantage of the XL Detect+’s 5″ LCD screen and 3X brighter display.
• Reduce expenses.
  Reduce your maintenance costs with reliability you can rely on, even in the most demanding inspection conditions
• Stay flexible.
  At just 4.3 lbs., the device is lightweight and portable, featuring a rugged carrying case with integrated insertion tube storage reel.
• Learn quickly.
  The intuitive interface includes Menu Directed Inspection (MDI) 1.1, an application to guide users through inspections and organize results for simpler reporting
• Experience true peace of mind.
  Get readily available assistance from Baker Hughes experts, wherever you are.
  Now with a 5” LCD screen for clear-cut inspections.
  The new XL Detect+ display is 85% larger, with crystal clear image quality unmatched in the industry. That means a simpler interface, less eyestrain on long inspections, and more accurate images right on your device. Because when you can see clearly, you improve POD, speed up your workflow, and deliver results with confidence.
• Applications:
  • Oil and Gas
  • Power Generation
  • Automotive
  • Aerospace
  • Food & Beverage
  • Pharmaceutical
  • Manufacturing

  Specifications:

  • OPERATING ENVIRONMENT:Tip Operating Temp : -25°C to 100°C (-13°F to 212°F) Reduced articulation below 0°C (32°F)
    System Operating Temp : -20°C to 46°C (-4°F to 115°F) LCD requires warm-up period below 0°C (32°F)
    Storage Temperature : -25°C to 60°C (-13°F to 140°F)
    Relative Humidity : 95% max, non-condensing
    Waterproof : Insertion tube and tip to 14.7 psi (1 bar, 10.2 m of H2 O, 33.5 ft of H2 O)
    Environmental : XL Detect+: Tested to IP65
  • SYSTEMCase Dimensions : 48.8 x 38.6 x 18.5 cm (19.2 x 15.2 x 17.3 in)
    System Weight : In Case: XL Detect+: 6.74 kg (14.87 lb)
    Without Case : XL Detect+: 1.98 kg (4.37 lb)
    Power (Lithium Ion Battery) : 8.4 V, 38 Wh (2 hour) 8.4 V, 75 Wh (4 hour)
    Power Supply : AC Input: 100-240 VAC, 50-60 Hz, 1.5 A Max DC
    Output: 9.5 V, 6.0 A
    Construction : Polycarbonate housings with integrated Versalon™(JP) bumpers
    Dimensions : 9.53 x 13.34 x 34.29 cm (3.75 x 5.25 x 13.50 in)
    LCD Monitor:
    XL Detect+ : Integrated 12.7 cm (5.0) active matrix VGA color LCD, Transmissive display.
    Joystick Control : 360° All-Way Tip articulation, menu access and navigation
    Button Set : Access user functions, measurement and digital functions
    Audio : Integrated 2.5 mm headset/microphone jack
    Internal Memory : XL Detect+: 4 GB Flash memory
    Data I/O Ports : One USB® 2.0 port
    Video Port : VGA Video Out
    Brightness Control : Auto and Variable
    Illumination Type : White LED
    Long Exposure : Via auto and manual mode
    White Balance : Factory default or user defined
  • STANDARDS AND COMPLIANCE CLASSIFICATIONS
    MIL-STD-810G : Tested to United States Department of Defense Environment Tests Sections 506.5, 507.5, 509.5, 510.5, 511.5, 514.6, 516.6, 521.3
    MIL-STD-461F : XL Detect+: Available upon request
    Standards Compliance : Group 1, Class A: EN61326-1 UL, IEC, EN CSA-C22.2:61010-1 UN/DOT T1-T8
    IP Rating : XL Detect+: Tested to IP65
  • CAMERA
    4.0 mm (0.157 in) Diameter Probes
    Image Sensor : 1/10 inch Color SUPER HAD CCD camera
    Pixel Count : 290,000 pixels
    Housing : Titanium
    6.1 mm (0.242 in) and 8.4 mm (0.331 in) Diameter Probes
    Image Sensor : 1/6 inch Color SUPER HAD™ CCD camera
    Pixel Count : 440,000 pixels
    Housing : Titanium
  • SOFTWARE
    Operating System : Real-time multi-tasking operating system
    User Interface : Simple drop-down menu-driven operation. Menu navigation using articulation joystick
    File Manager : Embedded file manager software supporting:
    File & Folder creation, naming, deleting Store to internal
    Flash (C:\) or USB ThumbDrive Copy between USB and C:\
    MDI Software (optional) : Provides user defined guided inspection Creates DICONDE compatible inspection files Creates MS Word® compatible inspection reports
    Audio Data : PC compatible (.AAC) file format
    Image Control : Invert, Zoom (5X digital) Image Capture and Recall
    Digital Zoom : Continuous (5.0X)
    Image Formats : Bitmap (.BMP), JPEG (.JPG)
    Video Format : MPEG 4
    Text Annotation : Built-in full screen text overlay generator Supports international language character sets 100 text line capacity
    Graphic Annotation : User placement of arrows
    Articulation Control : “Steer & Stay” articulation lock/fine articulation Tip
    “Home” return to neutral forward-tip orientation
    Software Updates : Field updateable via USB ThumbDrive
    Languages : English, Spanish, French, German, Italian, Russian, Japanese, Korean, Portuguese, Chinese, Polish
