Sonatest Veo3 Phased Array Flaw Detector For Sale with a Best Price offersthe greatest features of the popular Veo line while adding live TFM, user templates, and a PCAP touch interface .
The Veo3’s primary design components are performance and user-focused. The Veo3 genuinely assists you in inspecting with confidence because to its live concurrent multi-scan / multi-technique capabilities and outstanding and revolutionary digital technology.
Focus Where it Matters
Single Scan of Thicker Parts
Without restricting the amount of pixels per axis, the Veo3 can produce TFM images with up to 500K pixels and a maximum resolution of 100 pixels per mm. By combining time corrected gain with the TFM picture, the technician may evaluate thicker items more flexible and still adhere to ASME standards. And all it took was one scan. The Veo3 is equipped to handle the problems you face every day. In challenging applications, fault characterization and assessment have never been this simple.
Full Data Capture and Analysis
Sonatest Veo3 Phased Array Flaw Detector can record every piece of information obtained during Full Matrix Capture (FMC) scanning. In order to find trends and the rates at which flaws and corrosion are growing, more thorough analysis can be carried out, including a comparison with data from earlier inspections. If the inspector or expert needs assistance, the Sonatest UTStudio+ software package offers a wide range of features. Alternatively, the data can be exported and analyzed using different algorithms. Beyond simply the basic inspection, Sonatest offers the essential instruments.
Specifications:
PHASED ARRAY (32:128PR)
Multiscan Quantity : Up to 8 scans
Pulsers/Receivers : 32:128PR
Gain Range : 80dB
Sampling Frequency : 125 MHz @ 12-Bit
System Bandwidth : 0.2 to 23 MHz
Max Pulse Rate Frequency : 50,000 Hz
Pulse Voltage : 100-50V ActiveEdge©
Focusing Mode : Natural or Constant Depth/Path/Offset
S-Scan Resolution : Up to 0. 1°
L-Scan Resolution : Down to 1 element or Double Resolution
Max PA Beams (focal laws) : Up to 1024 beams
Tools – Measurements and Wizard : EXTRACTION BOX, 4 gates/A-Scan, TCG, DAC/Split-DAC
Onboard Scan Plan Tools : Onboard 3D live rendering Operating Time 6 hours (hot swappable batteries)
Onboard Reporting Tools : PDF auto-report, Export data to CSV file, Save screen capture
Onboard PDF Reader Integrated : Ability to load and read and PDF documents
Online Help Calibration : ACTIVE help genius for parameter optimisation procedures, reports
Standards: ISO18563 (EN16392) & EN12668
Operating Time: 6 hours (hot swappable batteries
Power Input: AC 110V/240V @ 50 Hz/60 Hz
Unit Dimensions: 115 x 220 x 225 mm (4.52 x 8.6)
Weight : 5.1 kg (11 lb) no battery, 460g
Environmental Rating : Designed for: IP66
Package Includes:
– Veo3 Phased Array Flaw Detector
– 2 Lithium Ion Batteries
– External USB Stick 8GB G3
– Ruler
– PA 15V 4A AC/DC Power Adapter
– Quick Start Guide – Hard Copy
– User Manual & Quick Start Guide USB
– Carry Strap
– Transport Case
– Screen Protector (Clear or Tinted)
– UTstudio Standard License
– Warranty Card
– Calibration Certificate
